首頁 > PEEK棒材規格
| 棒材規格表 | |||||
|---|---|---|---|---|---|
| 序號 Serial number | 直徑mm Diameter | 米重kg weight per meter | |||
| PEEK5600G | PEEK5600CF30 | PEEK5600GF30 | PEEK5600LF30 | ||
| 1 | 5 | 0.03 | 0.04 | 0.04 | 0.04 |
| 2 | 6 | 0.05 | 0.05 | 0.06 | 0.06 |
| 3 | 8 | 0.06 | 0.07 | 0.08 | 0.08 |
| 4 | 10 | 0.11 | 0.13 | 0.14 | 0.13 |
| 5 | 12 | 0.16 | 0.17 | 0.19 | 0.18 |
| 6 | 15 | 0.25 | 0.27 | 0.29 | 0.28 |
| 7 | 16 | 0.27 | 0.28 | 0.31 | 0.29 |
| 8 | 18 | 0.36 | 0.38 | 0.42 | 0.39 |
| 9 | 20 | 0.45 | 0.45 | 0.53 | 0.51 |
| 10 | 22 | 0.53 | 0.56 | 0.61 | 0.58 |
| 11 | 25 | 0.67 | 0.65 | 0.76 | 0.72 |
| 12 | 26.7 | 0.76 | 0.8 | 0.88 | 0.83 |
| 13 | 28 | 0.84 | 0.92 | 1.03 | 0.95 |
| 14 | 30 | 0.94 | 0.97 | 1.18 | 1.02 |
| 15 | 32 | 1.07 | 1.12 | 1.29 | 1.22 |
| 16 | 35 | 1.35 | 1.34 | 1.42 | 1.35 |
| 17 | 38 | 1.52 | 1.66 | 1.81 | 1.71 |
| 18 | 40 | 1.71 | 1.76 | 2.02 | 2.02 |
| 19 | 42 | 1.91 | 2.05 | 2.22 | 2.11 |
| 20 | 45 | 2.13 | 2.32 | 2.56 | 2.39 |
| 21 | 48 | 2.52 | 2.62 | 2.85 | 2.71 |
| 22 | 50 | 2.66 | 2.81 | 3.13 | 3.14 |
| 23 | 53 | 2.95 | 3.15 | 3.45 | 3.26 |
| 24 | 55 | 3.14 | 3.64 | 3.72 | 3.15 |
| 25 | 60 | 3.95 | 4.16 | 4.6 | 4.21 |
| 26 | 65 | 4.37 | 4.76 | 5.42 | 4.37 |
| 27 | 70 | 5.51 | 5.61 | 6.23 | 5.82 |
| 28 | 75 | 5.99 | 6.36 | 6.92 | 6.54 |
| 29 | 80 | 7.08 | 7.61 | 7.94 | 7.82 |
| 30 | 85 | 7.67 | 8.22 | 8.81 | 8.43 |
| 31 | 90 | 8.33 | 9.39 | 10.21 | 9.67 |
| 32 | 95 | 9.16 | 10.13 | 11.08 | 10.42 |
| 33 | 96.5 | 9.66 | 10.28 | 11.17 | 10.64 |
| 34 | 100 | 10.73 | 10.81 | 12.09 | 11.44 |
| 35 | 110 | 12.93 | 12.91 | 14.59 | 13.57 |
| 36 | 115 | 13.53 | 14.78 | 16.06 | 15.22 |
| 37 | 120 | 15.44 | 16.42 | 17.62 | 16.67 |
| 38 | 125 | 16.18 | 17.21 | 18.73 | 17.74 |
| 39 | 130 | 20.08 | 19.21 | 21.82 | 19.57 |
| 40 | 140 | 20.55 | 21.66 | 23.78 | 22.89 |
| 41 | 150 | 23.81 | 26.29 | 27.64 | 26.36 |
| 42 | 160 | 26.85 | 29.81 | 33.71 | 30.67 |
| 43 | 165 | 29.01 | 30.18 | 33.89 | 31.02 |
| 44 | 170 | 30.22 | 32.49 | 35.04 | 33.43 |
| 45 | 180 | 33.99 | 35.93 | 38.94 | 36.88 |
| 46 | 190 | 37.86 | / | / | / |
| 47 | 200 | 43.26 | / | / | / |
| 48 | 220 | 50.79 | / | / | / |
| 49 | 250 | 65.51 | / | / | / |
| 注：棒材具體尺寸規格及重量以實際發貨為準，上述數據僅供參考 | |||||
